適用規格
Specifications: |
|
|
|
|
|
|
|
|
|
|
|
|
|
Application Model |
LS-030L |
LS-040L |
LS050L |
LS063L |
LS080L |
LS100L |
裸品外徑
Naked part outside dia.(m/m) |
3.0±0.02 |
4.0±0.02 |
5.0±0.02 |
6.3±0.02 |
8.0±0.02 |
10.0±0.02 |
裸品長度
Naked part case length(m/m) |
5.1~5.3 |
5.3~5.6 |
5.3~5.6 |
5.3~5.7 |
5.3~8.6 |
10.5 |
運轉速度
Production speed(pcs/min) |
60 |
70 |
70 |
70 |
70 |
70 |
膠管長度
Length of rolled sleeves(M/roll) |
400M Max. |
消耗電力
Power consumption 220V Sφ |
1
HP + 1 KW |
機械尺寸
Machine size(cm) |
L X
W X
H |
L X
W X
H |
L X
W X
H |
L X
W X
H |
L X
W X
H |
L X
W X
H |
|
136X98X175 |
136X98X175 |
130X98X180 |
130X98X180 |
130X98X180 |
130X98X180 |
淨
重 Net
weight(kg) |
530 |
530 |
530 |
530 |
530 |
530 |
|
|
|
|
|
|
|
Application Model |
LS-040 |
LS050 |
LS060 |
LS063 |
LS080 |
LS081 |
裸品外徑
Naked part outside dia.(m/m) |
4.0±0.02 |
5.0±0.02 |
6.0±0.02 |
6.3±0.02 |
8.0±0.02 |
8.0±0.02 |
裸品長度
Naked part case length(m/m) |
7.0~7.8 |
7.8 or 12.0 |
7.8 or 12.0 |
7.8 or 12.0 |
11.8or16.0 |
16.0or20.0 |
運轉速度
Production speed(pcs/min) |
80 |
80 or 90 |
80 or 90 |
80 or 90 |
80 |
70 |
膠管長度
Length of rolled sleeves(M/roll) |
400M Max. |
消耗電力
Power consumption 220V Sφ |
1
HP + 1 KW |
機械尺寸
Machine size(cm) |
L X
W X
H |
L X
W X
H |
L X
W X
H |
L X
W X
H |
L X
W X
H |
L X
W X
H |
|
136X98X175 |
130X98X180 |
130X98X180 |
130X98X180 |
130X98X180 |
130X108X180 |
淨
重 Net
weight(kg) |
530 |
530 |
530 |
530 |
530 |
600 |
|
|
|
|
|
|
|
Application Model |
LS-100 |
LS101 |
LS130 |
LS131 |
LS160 |
LS161 |
裸品外徑
Naked part outside dia.(m/m) |
10.0±0.02 |
10.0±0.02 |
12or13±0.02 |
12or13±0.02 |
16.0±0.02 |
16.0±0.02 |
裸品長度
Naked part case length(m/m) |
12or16or20 |
25or30 |
16or20or26 |
32or36 |
20or26or32 |
32or36 |
運轉速度
Production speed(pcs/min) |
70or65 |
55 |
55 |
40 |
50 |
40 |
膠管長度
Length of rolled sleeves(M/roll) |
400M Max. |
消耗電力
Power consumption 220V Sφ |
1
HP + 1 KW |
1.5HP + 1.2KW |
機械尺寸
Machine size(cm) |
L X
W X
H |
L X
W X
H |
L X
W X
H |
L X
W X
H |
L X
W X
H |
L X
W X
H |
|
136X98X175 |
130X118X180 |
130X128X180 |
130X128X180 |
130X128X180 |
130X128X180 |
淨
重 Net
weight(kg) |
600 |
600 |
650 |
650 |
650 |
650 |
|
|
|
|
|
|
|
Application Model |
LS-181 |
LS201 |
LS221 |
LS251 |
|
|
裸品外徑
Naked part outside dia.(m/m) |
18.0±0.02 |
20.0±0.02 |
22±0.02 |
25±0.02 |
|
|
裸品長度
Naked part case length(m/m) |
30~50 |
30~50 |
30~50 |
30~50 |
|
|
運轉速度
Production speed(pcs/min) |
45 |
45 |
40 |
40 |
|
|
膠管長度
Length of rolled sleeves(M/roll) |
400M Max. |
消耗電力
Power consumption 220V Sφ |
1.5HP + 1KW x 2 |
機械尺寸
Machine size(cm) |
L X
W X
H |
L X
W X
H |
L X
W X
H |
L X
W X
H |
|
|
|
136X98X175 |
130X118X180 |
130X128X180 |
130X128X180 |
|
|
淨
重 Net
weight(kg) |
750 |
750 |
750 |
750 |
|
|
備 注 : |
|
Remark : |
|
|
|
|
1.
各種機型所適用鋁殼長度於訂購時需加指定 , 其適用範圍請事先與本公司商洽 . |
1. Aluminum case length should be specified
when ordering and pre- negotiation with our engineers on application range is re-quired . |
|
2.
本公司保留機器修改或變更之權利 .
|
2.Any
modification or change on machines may be adopted witch- out notice . |
|
|
